Agilent Technologies 6850 Series - Covers, modules, and electronics

Detectors
6850
6850
Released: April 2004 6850 Series Gas Chromatograph Service Procedures 153
Covers, modules, and electronics
Description Part no. Qty.
Covers and electronics
1. Flame photometric detector
assembly
1
Single wavelength FPD
G1535-60555
Dual wavelength FPD (not shown) G1535-60565
2. Detector top cover, single FPD (not
shown)
G1535-80550 1
2A. Detector top cover, dual FPDs
G1535-80560 1
3. Electronics cover pan
G1535-00120 1
4. Electronics top cover G1535-80540 1
Cover assembly (not shown)
G1535-80520 1
5. Actuator solenoid bracket
(optional)
G1580-00070 –
6. Printed circuit board G1535-60010 1
Spring (not shown) 1460-1160 1
Modules
7. Replacement FPD module
G1535-60720
8. Replacement EPC FPD module, Kit
(replaces either type)
G1535-60720
