Oven

6850

Released: April 2004 6850 Series Gas Chromatograph Service Procedures 209

Replacement parts

Fans

Intake fan assembly

G2630-61300

Fan grille

3160-0249

Injection port fan assembly

G2630-61320

Front panel

G2630-00270

Fan at rear of GC

(not shown)

G1530-60510
