Released: April 2004 6850 Series Gas Chromatograph Service Procedures 156

Flow module

G2630-61210

G2630-61220

FID

TCD

Detector module assembly kits

Pneumatics connector covers

G2630-00680

Screw, M4 × 12 mm (8 places)

0515-2556

FID module shown
