Inlets and valves

6850

Released: April 2004 6850 Series Gas Chromatograph Service Procedures 41

Inlet flow modules

Purged packed inlet

For replacement parts for any inlet flow module,

see “Any inlet flow module” on page 1-42.

Purged packed inlet

G2630-61245

module assembly kit
