Released: April 2004 6850 Series Gas Chromatograph Service Procedures 20

5. Disconnect the cover switch connectors.

Caution

Be careful not to pull the metal contacts off

of the switch when disconnecting the wires.

Front cover (with keyboard and

display)

WARNING

Burn hazard. The oven may be very hot.

Before beginning, turn off the oven and allow

it to cool.

Disconnect
