Covers

6850

Released: April 2004 6850 Series Gas Chromatograph Service Procedures 10

Replacement parts

External covers

HP 6850 Series

GC System

Front panel housing

Marquee

G2630–40170

G2630–60630

G2630–40140

Detector cover

Screw, shoulder,

M4 x 9 mm

0515–3005
