Electronics
6850
6850
Released: April 2004 6850 Series Gas Chromatograph Service Procedures 245
Cables
Table 1-1 lists the replaceable cables used in the
6850 GC, along with the cable starting and
ending locations.
Table 1-1. 6850 GC Cables
Cable Part number From To
Inlet/detector/aux cable assy G2630-60750 Main board Inlet, detector, aux heaters
AD/inlet/detector cable assembly G2630-60800 Main board flow modules, detector interface
Front display cable assembly G2630-60760 Main board Front display board
Flapper/AC cable assembly G2630-60780 AC board Oven flap motor
PTV extension cable G2617-60530 PTV cryo valve Converter board
AUX EPC extension cable G2630-60795 AUX EPC Main board
Line connector cable assembly G2630-61005 AC board Line filter
Cooling fan cable G2630-60990 Main board Cooling fans
