Oven
6850
6850
Released: April 2004 6850 Series Gas Chromatograph Service Procedures 228
CO
2
cryogenic cooling kit
If not installed, install the flanged column
hanger, part number G2630-80800. Install the
hanger so the flange is closest to the heater
shroud.
This kit adds CO
2
cryogenic oven cooling to an
Agilent 6850 Gas Chromatograph. The GC must
have firmware revision A.03.00 or higher.
The kit contains:
Accessory G2625A Qty.
Cryo chassis 1
Chassis cover 1
Tubing coil 1
Bracket for tubing coil 1
Restrictor tube 1
1/16-inch Swagelok nut 2
Port connector 1
Filter 1
Screw, M4 x 12 mm, for cryo chassis and cover 8
Column hanger, flanged 0*
Installation sheet (this document) 1
1/16-inch Vespel ferrule 2
*Column hanger, part number G2630-80800, must be
ordered separately if needed.
