Inlets and valves

6850

Released: April 2004 6850 Series Gas Chromatograph Service Procedures 46

Sampling valves, continued

Figure 1-8. Sampling valve replacement parts, continued

Valve inlet insert assembly

G2630-61080

Valve box lid

G2630-00730

Valve box chassis

G2630-61400

Inlet chassis

G2630-40210

Diaphragm (for gas or liquid valve)

Continued

0101-0760
