Electronics
6850
6850
Released: April 2004 6850 Series Gas Chromatograph Service Procedures 256
Transformer
Table 1-4. Transformer replacement kit
(G2630-61570) contents
Replace the transformer and pad
WARNING
Shock hazard. Before beginning, turn off the
instrument and disconnect the power cord.
Caution
You are working near printed circuit boards.
Follow standard ESD precautions.
Description Part number Qty.
M10 nut (salvage from installed
unit)
0535-0189 2
M10 cone washer (salvage from
installed unit)
1460-2403 1
Transformer (included in this
G2630-61570 kit)
G2630-60970 1
Transformer mounting pad (sup-
plied with G2630-60970 trans-
former)
G2630-21020 1
Replacement guide G2630-90347 1
