Tunable Lasers How to Perform a Wavelength Sweep
128 Agilent 8163A/B, 8164A/B, and 8166A/B User’s Guide, Fourth Edition
13 Enter 1.000 and press Enter.
14 Move to [Dwell] and press Enter.
15 Enter 0.5000 and press Enter.
16 Press the [Active] hardkey on the front panel of your Tunable Laser
module to enable the optical output.
17 Press [Run Swp] to start the sweep. The screen in Figure 72
appears.
18 The wavelength is swept automatically but you can:
a press [Stop] to end the sweep, or
b press [Pause] to pause the sweep. The screen in Figure 73 appears. You
can:
–Press [Continue] to continue sweeping automatically.
–Press [Prev] or [Next] to sweep manually.
–Press [Stop] to end the sweep.
Figure 72 Executing a Stepped Sweep
