Getting Started How to Change the Value of a Parameter
54 Agilent 8163A/B, 8164A/B, and 8166A/B User’s Guide, Fourth Edition
1 Press [Edit]. The first digit before the decimal point will be
highlighted first, as shown in Figure 23.
2 If you want to select another digit to edit, use the left or right cursor
key.
3 Enter the new value for the digit by using the numerical keypad, the
up and down cursors or turning the modify knob.
4 Repeat steps 2 and 3 to continue editing the value.
5 When you have finished editing the value, press Enter. The edited
value becomes the new value of the parameter.
To change the wavelength from 1540.000 nm to 1525.000 nm:
1 Move to the wavelength parameter for a Tunable Laser module and
press [Edit]. The most significant digit is highlighted.
2 Press the left cursor once to highlight the digit four.
3 Press the down cursor twice to change the value of the digit to two.
4 Press the right cursor once to move the cursor one digit right.
5 Press the up cursor five times to change the value of the digit to five.
Press Enter to end the editing.
Figure 23 The First Digit Before the Decimal Point is Highlighted First
