Installer manual AlphaVision ML Rev. 3.60 01-01-2015 112
ID1 user
ML
XL
Description
502
x
Installer
503 .. 510
x
(reserved)
900
x
User 1 .. 1500 (TAG-users access control)
961..968
x
Automatic clock 1 .. 8
999
x
Keyswitch
When ID1 is used to describe a zone the following table applies:
ID1 zone
ML
XL
Description
1 .. 44
x
Zone 1 .. 44
1 .. 616
x
Zone 1 .. 616
When ID1 is used to describe a module the following table applies:
ID1 module
ML
XL
Description
1 .. 4
x
Keypad 1 .. 4
1
x
Prox Reader
0
x
Control panel
1 .. 3
x
Zone expansion module 1 .. 3
1 .. 40
x
Keypad 1 .. 40
41 .. 80
x
Prox Reader 1 .. 40
81 .. 120
x
RO module 1 .. 40
121
x
Control panel
122 .. 196
x
Zone expansion module 1 .. 75
197
x
XLCOM plug-on board
198 .. 199
x
(reserved)
200
x
IP dialer (integrated)
201
x
(reserved)
202
x
PSTN dialer (plug-on)
203
x
(reserved)
204
x
DLM-600 GPRS (back-up) dialer (via RS-485)
205
x
(reserved)
ID2 can have the value 0 if the section is not know or not relevant. If there is section information then this is
shown as a 2-digit (decimal) number. For the AlphaVision ML the section description lies between 01 and
04. For the AlphaVision XL the value lies between 01 and 32.
Note: if an event is linked to more than one section then only 1 section will be displayed. Normally this will
be the lowest section number.
