Installer manual AlphaVision ML Rev. 3.60 01-01-2015 114

Adres 1

Adres 2

Adres 3

Adres 4

Adres 5

Adres 6

Adres 7

Adres 8

APPENDIX E: KEYPAD ADDRESSING

For addressing of the keypads dipswitches 1-3

are used. Dipswitch 4 is not used.

APPENDIX F: EXPANSION MODULE ADDRESSING

Expansion modules are addressed with the four

dipswitches.

Adres 1

Adres 2

Adres 3

Adres 4

Adres 5

Adres 6

Adres 7

Adres 8

Adres 9

Adres 10

Adres 11
