Gebruikershandleiding AlphaVision ML Rev. 1.2 – 24-05-2006 96
OPEN ZONES
WALKTEST ZONES
TEST LED & LCD
NO OPEN ZONES
START WALKTEST
ALLE LEDS ON
VIEW WALKTEST
ALLE LEDS OFF LCD LINE 2 ON
LCD LINE 2 OFF
LCD LINE 1 ON
LCD LINE 1 OFF
TEST OUTPUTS OUTPUT 1 OUTPUT 1 ACTIVE
OUTPUT 8
TO PREV. MENU ?
OUTPUT 8 ACTIVE
RESET USER CODE
ARE YOU SURE ? RESET
FAC. DEFAULTS
TO PREV. MENU ?
OK=YES *= EXIT
FACTORY DEFAULT
ok
ok
ok
ok
ok ok
ok
ok ok
ok
ok
ok
ok
ok
ok ok
ok ok
TEST KEYS
ok
LS OUTPUT
LS OUTPUT ACTIVE
CONNECT VIA IP IP CONNECTING..
ok
SEND TESTREPORT SEND TESTREPORT:
ok
ZONE WALKTEST ZONE 01 ZONE xx OK
ok ok
TESTREPORT SENT..
ok
ZONE NAME
ZONE 44
TESTMODE xx hour SAVED
View open zones
When the system cannot arm because of open zones, the user is alerted during arming. The message ‘CAN
NOT ARM, OPEN ZONES’ is displayed and the alert buzzer is sounded. The ‘Open zone’ menu shows a list of
all open zones. The Open zones function is accessible for both the installer and the supervisor. Opening this
function will show a list of all open zones.
Zone walktest
To perform a walktest of all available zones, the function Walktest can be used. Select the ‘Walktest’ option
and press <#/OK> to start the test. The display will show “Start Walktest, …busy…” When performing a
walktest, all zones need to be activated one by one. Each time a detector is triggered, the keypad will sound
an alert beep and the specific zone is shown on the display, with its zone name and RF reception strength
(only applicable to wireless zones, e.g. RF=108).
For hardwired components the displayed reception strength has no meaning and will be shown as RF=099.
When the AlphaVision ML control panel uses a wireless receiver unit, the measured reception strength is
shown.
