Installer manual AlphaVision ML Rev. 3.60 01-01-2015 16

Connections on the AlphaVision ML main board

Connectors for

speech plug-on

Connection for

wireless module

Loudspeaker

output

Power

supply

LAN

connection

12 hardwired

inputs EOL

Bus

(

(Alphn)

Alarm output AL

1 +

AL2

(Potential free contact NO/NC,

selectable by jumpers below)

OC3 (Tamper switch

OC4 (200mA) collector)

(

(Alphn)

Tamper switch

White connector for

battery-pack

RS-485 bus

Connectors for PSTN

plug-on

Connectors for

GSM/GPRS

RS-232 connector

(

(Alphn)
