Controller / User Interface | 4-11
ALARMS and WARNINGS Menu Screen
The ALARMS and WARNINGS screen (Figure 4-3) displays active ana-
lyzer alarm conditions (Current Alarms and Warnings screen) that have
been set by the built-in diagnostics function and a history of alarms and
warnings that have been reset (Alarm Log or Warnings Log screen). The
alarms are read-only.
Figure 4-4.
Active alarms displayed,
Current Alarms (example
screen).
Cell Temperature
Heater Temperature
HOME ALARMS STATUS SETUP
Figure 4-5.
No active alarms,
Current Alarms screen.
No alarms
HOME ALARMS STATUS SETUP
Viewing Current Alarms and Warnings
All active alarms and warnings are displayed on the Current Alarms and
Warnings screen. Each line will occupy one alarm or warning description
and up to six active alarms or warnings can be displayed on the screen at
once. If more than six are active, use the DOWN arrow key to scroll down
the list. The alarm or warning at the top of the list is most recent; the
alarm or warning at the bottom is the oldest.
To view active conditions, select Current Alarms and Warnings and press
ENTER. If there are alarms active, the alarm description is displayed (Fig-
ure 4-4). If no alarms are active, “No alarms” is displayed (Figure 4-5).
For a complete list of alarms and warnings generated by the analyzer,
refer to the “Maintenance and Troubleshooting” chapter.
> Current Alarms and Warnings
Alarm Log
Warnings Log
HOME ALARMS STATUS SETUP
Figure 4-3.
ALARMS and
WARNINGS screen.
NOTE
