Installation and Start-Up | 3-3
Uncrating and Inspecting the Analyzer
The analyzer, along with its associated sample system, is shipped pre-
mounted on unistruts (or on a backpan) either alone in a crate or in a
crated weatherproof shelter. The Optical Bench Assemblies are shipped in
a separate box within the Analyzer crate.
Upon receiving the analyzer system, remove the shipping crate and
check the exterior of the shelter and/or analyzer for damage. Remove the
Optical Bench Assembly from its box and check it for any physical dam-
age. Replace the Optical Bench Assembly in its box until it is ready to be
installed.
Open the shelter and/or analyzer and check to ensure that all of the com-
ponents within are secure and that there is no physical damage. Check
that all of the components and wiring within the Electronics Enclosure
and Oven/Sample System Enclosure are secure and that there is no physi-
cal damage.
After the inspection, close and secure all doors with at least one latch.
This will keep the electronics equipment secure and will prevent dam-
age to the doors and electronic components during installation.
For non-shelter systems, avoid damaging the analyzer piping or
instrumentation by lifting it out of its shipping crate using only its
unistruts or backpan, or metal enclosure. DO NOT use any external
instrument or tubing connectors as a handle for lifting.
The analyzer (on unistruts) weighs approximately 164 kg (360 lb)
depending on the system. Use caution when lifting it from its crate.
General Installation Information
Figure 3-1 illustrates an example of the layout of components within the
IPS-4 Analyzer. The components in the Electronics Enclosure generally
do not change. However, many of the sample system components in the
Oven/Sample System Enclosure in this example illustration are optional
and are configured specifically for the application.
Final “As-Built” drawings for your analyzer are located in the
Documentation Package shipped with the analyzer and in the
“Supplemental Information” section of this manual.
!
