User Web Interface | 7-3
Web Interface Components
The Web Interface is divided into six sections. Navigation buttons lo-
cated on the left-hand side of the screen are used to view analyzer sta-
tus, alarms, trends, and spectra; view and change analyzer settings; and
transfer data.
The information displayed on the right-hand side varies depending on
the selected section.
• The web interface header displays the “state” of the analyzer and the
concentration of the analytes being measured. This section is read
only.
- Examples of “states” include Zero, Span, and Measure. These and
other states are described in detail under “System Status Messages
(HOME Screen),” in Chapter 4.
- Analytes are factory set. Up to six analytes can be displayed.
• Alarm and warning notifications are displayed in the banner located
below the header on every screen. The most current notification is
displayed with 1 of x if there are multiple active notifications.
Messages
While working from the Web Interface, the following condition applies:
The Web Interface is shipped from the factory without password pro-
tection. All configurable parameters can be changed through the web
interface.
Trend and Spectral data are stored in temporary memory. For security
reasons, temporary data can not be stored directly onto the computer
hard drives. Any intentional or unintentional recycling of power will
cause a loss of saved data.
Data cannot be saved directly to your computer. To make a record of
displayed information use your PC screen capture function and paste
the image into another program.
NOTE
