Controller / User Interface | 4-15
To view other sub-menu items under this screen, use the UP/DOWN arrow
keys to scroll through the list of analyzer functions to select the appropri-
ate sub-menu item.
Detailed descriptions of each sub-menu item – and the parameters under
each – are listed in the following pages (each listed as a heading in this
manual). The list of available sub-menu items includes:
• Calibration Control
• Relays
• Current Outputs
• Setpoints
• Diagnostics
• System Settings
• Modbus
Figure 4-11.
SETUP menu screen.
> Calibration Control
Relays
Current Outputs
Setpoints
Diagnostics
System Settings
HOME ALARMS STATUS SETUP
SETUP Menu Screen
The SETUP screen (Figure 4-11) provides access to the sub-menu screens
containing the functional parameters that control the operation of the
analyzer. This screen allows the user to set up certain parameters.
The settings for your analyzer have been configured at the factory to
meet specified customer requirements. Changing the factory-set con-
figuration could cause the analyzer to operate incorrectly.
!
CAUTION
To Next Page
