Ametek IPS-4 User Manual

4-34 | IPS-4 Dual Bench (UV / IR) Analyzer
Figure 4-29.
Valve Diagnostics
Screen.
Valve Diagnostics
►Diagnostics State O󰀨
Valve 1 On
Valve 2 O󰀨
Valve 3 O󰀨
Valve 4 O󰀨
HOME ALARMS STATUS SETUP
Valve Diagnostics
Force valve contacts on or off to test the solenoid valves.
Figure 4-30.
Lamp Diagnostics
Screen.
Lamp Diagnostics
►Wavelength 0.0
Measurement 16804
Dark Read 16718
Absorbance 0.1
Pixel 0
HOME ALARMS STATUS SETUP
Lamp Diagnostics
Monitor detector operation for a given wavelength.
System Settings Screen
The System Settings screen (Figure 4-31) allows the user to view and/or
setup analyzer system parameters.
Figure 4-31.
System Settings
Screen.
► Log in/Set Passwords
Backup/
Restore
Ethernet Network
System
Customization
HOME ALARMS STATUS SETUP
