4-32 | IPS-4 Dual Bench (UV / IR) Analyzer
Figure 4-23.
Pressure Limits
Setpoints Screen.
Pressure Limits
Cell Pres High Limit 142-15.2 PSI
Cell Pres Low Limit 142-15.2 PSI
Pres X 2 High Limit 0 PSI
Pres X 2 Low Limit 0 PSI
Manifold Pres High Limit 70-100
PSI
HOME ALARMS STATUS SETUP
Figure 4-24.
Temperature Limits
Setpoints Screen.
Temperature Limits
Bench Deviation Limit 2º C
Bench Set Point 50º C
Heater Deviation Limit 0º C
Heater Set Point 190º C
HOME ALARMS STATUS SETUP
