Installation and Start-Up | 3-7
The surrounding ambient temperature of the analyzer should be main-
tained between -20 °C to +50 °C (-4 °F to +122 °F). If the analyzer system
is mounted within an AMETEK-designed shelter, these conditions are
taken into consideration in the design of shelter.
To mount the analyzer:
Figure 3-2a and 2b is an example of an analyzer layout. Mounting
configuration and layout for your analyzer system may vary. Refer
to the Final “As-Built” drawings in the analyzer Documentation
Package.
Non-Shelter Installations:
In a suitable, accessible location, mount the analyzer on a vibration-free
wall or instrument rack.
Shelter Installations:
In a suitable, accessible location, install the analyzer in a vibration-free
location.
Refer to customer-specific Final “As-Built” shelter drawings in the
analyzer Documentation Package.
Outdoor Installations:
In most cases, the analyzer must be shielded from harsh environmental
elements such as wind, rain, and sun. In these cases a rain shelter or sun
shade is required.
Also, proper water drainage must be considered in the mounting location
to allow for suitable and safe working conditions for service personnel.
NOTE
NOTE
