3-32 | IPS-4 Dual Bench (UV / IR) Analyzer
Figure 3-8.
Relay Setup screen
(Relay 1).
Relay 1
> Function Disable
Source None
Value 0
Delay 0 Sec
HOME ALARMS STATUS SETUP
9. View the relay settings. To do this:
a. Press the SETUP soft key to view the SETUP menu screen. Scroll
down to select Relays and press ENTER to display the Relay
screen. Scroll down to select Relay 1 and press ENTER to display
the Relay 1 screen (Figure 3-8).
Check the Relay 1 Function (operational status setting for this
relay), Source (species), Value, and Delay (zero point) settings/
values and compare them to the settings/values listed on the
analyzer documentation shipped with the analyzer to ensure they
correspond.
b. Check the other relays, comparing their settings/values to
their corresponding settings/values listed on the analyzer
documentation.
If any of the settings need to be changed, refer to “Relay Setup
Screens” in Chapter 4 for details.
10. If using an Ethernet connection to communicate with the analyzer,
set up the Ethernet parameters as described in the section “Ethernet
Network Screen” in Chapter 4.
11. After approximately 2–3 hours, at which time the entire sample system
has now reached its normal operating temperature (application-spe-
cific) and has stabilized, the system will leave the Not Ready state for
the first time.
Temporarily open the Electronics Enclosure door and listen for an
intermittent clicking sound, which indicates the Xenon Flash Lamp is
on (flashing).
If there is no clicking sound, and the analyzer is in a state other than
the Not Ready state, this can indicate problems with the wiring. If
necessary, power down the analyzer and check all associated wiring.
