SOLT – Coax Menu
Key Sequence: Shift, Calibrate (2) > DUT Port Setup > Setup User-Defined > Enter
Edit Name: Press this soft key to use the Text Entry feature (refer to the Text
Entry section in the user guide for your instrument). Enter a name for your
setup.
Open: Press this soft key to display the Open menu. Enter any offset length
and capacitance values. See Figure 6-29 on page 6-30.
Short: Press this soft key to display the Short menu. Enter any offset length
and inductance values. See Figure 6-29.
Back: Press this soft key to return to the “DUT Port Setup Menu (Coax)”
on page 6-29.
Figure 6-31. SOLT – Coax Menu
Open
Edit Name
SOLT(4) – USER4
Short
SOLT – Coax
Back
To Next Page
