The VNA Master and LMR Master connectors are described in the user guide for your
instrument.
Table 1-1. Instrument Terminology used in this Manual
Term Instrument Models
VNA Master
MS2024B, MS2025B, MS2034B, MS2035B
MS2026B, MS2028B
MS2026C, MS2027C, MS2028C, MS2036C, MS2037C, MS2038C
MS202xB MS2024B and MS2025B
MS203xB MS2034B and MS2035B
MS20xxB MS2024B, MS2025B, MS2034B, MS2035B
MS2026B MS2026B with Firmware Version 2.0 and higher
MS2028B MS2028B with Firmware Version 2.0 and higher
MS202xC MS2026C, MS2027C, and MS2028C
MS203xC MS2036C, MS2037C, and MS2038C
MS20xxC MS2026C, MS2027C, MS2028C, MS2036C, MS2037C, MS2038C
LMR Master S412E
S412E S412E
Note
MS20xxB is used in this manual to refer ONLY to models MS2024B, MS2025B,
MS2034B, and MS2035B. When referring to models MS2026B and MS2028B, the
full model numbers are specified and are never abbreviated.
