VNA View Menus 6-3 Domain Setup Menus
Vector Network Analyzer MG PN: 10580-00289 Rev. K 6-13
Distance Info List Box for Cable
Key Sequence: Freq/Time/Dist > Additional Dist Setup > Distance Info
Distance Info List Box for Waveguide
Key Sequence: Freq/Time/Dist > Additional Dist Setup > Distance Info
(Refer to “Time and Distance Information” on page 8-17.)
Figure 6-11. Distance Information List Box for Cable
Figure 6-12. Distance Information List Box for Waveguide
