Anritsu MS2024B - Bias Tee Menu

Bias Tee, Option 10 10-5 Bias Tee Menus (MS20xxC, MS2026B, and MS2028B)
Vector Network Analyzer MG PN: 10580-00289 Rev. K 10-9
Bias Tee Menu
Off: Press this soft key to turn the Bias Tee function Off.
External: Press this soft key to activate the External Bias Tee connection.
Both Port 1 and Port 2 external bias tees are activated.
Internal: Press this soft key to select the internal source for Bias Tee voltage.
The internal source is directed to either Port 1 or Port 2. Use the Int Port
Selection soft key in the Bias Tee Setup menu to select a port.
Back: Press this soft key to return to the “Bias Tee Setup Menu” without
changing the current Bias Tee setting.
Figure 10-8. Bias Tee Menu – MS20xxC
Back
Off
External
Internal
Bias Tee
