Freq/Dist Menu (Distance-Based)
Start Dist: Press this soft key to set the start distance in units of meters or
feet. If you enter a start distance that is higher than the currently-set stop
distance, and if CAL = On, then the start distance is set to the same value as
the stop distance. If you enter a start distance that is higher than the
currently-set stop distance, and if CAL = Off, then both start and stop distance
are set to the new distance.
Stop Dist: Press this soft key to set the stop distance in units of meters or
feet. If you enter a stop distance that is lower than the currently-set start
distance, and if CAL = On, then the stop distance is set to the same value as
the start distance. If you enter a stop distance that is lower than the
currently-set start distance, and if CAL = Off, then both stop and start distance
are set to the new distance.
Distance Info: Press this soft key to open the Distance Info dialog box. The
upper portion of the dialog box displays cable information, such as cable loss
and propagation velocity. the lower portion of the dialog box displays
parameter information. You can use the rotary knob or the arrow keys to scroll
through the list, which may have additional information beyond the lower edge
of the dialog box. For more information about this dialog box, refer to the
images in Section “Distance Info List Box for Cable” on page 6-13 and
Section “Distance Info List Box for Waveguide” on page 6-13 and also to the
descriptions in Section 8-6 “Time and Distance Information” on page 8-17 and
Section 9-6 “Distance Information” on page 9-6.
Start Freq: Press this soft key to set the start frequency in units of Hz, kHz,
MHz, or GHz. If you enter a start frequency that is higher than the
currently-set stop frequency, and if CAL = On, then the start frequency is set
to the same value as the stop frequency. If you enter a start frequency that is
higher than the currently-set stop frequency, and if CAL = Off, then both start
and stop frequency are set to the new frequency.
Stop Freq: Press this soft key to set the stop frequency in units of Hz, kHz,
MHz, or GHz. If you enter a stop frequency that is lower than the currently-set
start frequency, and if CAL = On, then the stop frequency is set to the same
value as the start frequency. If you enter a stop frequency that is lower than
the currently-set start frequency, and if CAL = Off, then both stop and start
frequency are set to the new frequency.
Units
mft:Press this soft key to set the center frequency in units of Hz, kHz,
MHz, or GHz. The center frequency can be set with the arrow keys, the rotary
knob, or the number keypad. When using the number keypad, the menu
displays soft keys with Hz, kHz, MHz, and GHz units. Pressing the Enter key
has the same effect as pressing the MHz soft key.
More: Press this soft key to open the “DTF Setup Menu” on page 7-6.
Figure 7-3. Field View Frequency Menu (Distance-Based)
