Anritsu MS2024B - Ms20 Xxb 1-Path 2-Port Calibration

VNA Measurements 4-7 Calibration Considerations
Vector Network Analyzer MG PN: 10580-00289 Rev. K 4-17
MS20xxB 1-Path 2-Port Calibration
1VNAMaster
2 Optional Test Port Cable at Port 2
3 Optional Test Port Cable at Port 1
4 Through Connection (Port 1 Connects to Port 2)
5 OSL (Open, Short, Load) Precision Calibration Components
Figure 4-13. 2-Port Calibration (LMR Master and MS20xxB)
Note
For a “Through” connection, connect the ends of the Male and Female cables
together.
OPEN
SHORT
LOAD
1
5
2
4
3
