Additional Dist Setup Menu (Waveguide)
Key Sequence: Freq/Time/Dist > Additional Dist Setup
Distance Info: Press this soft key to open the Distance Info List Box to find
helpful distance and parameter information. For a view of the list box
information, refer to Figure 6-12. The list box contains information such as the
start and stop frequencies, start and stop distances, number of data points,
windowing and processing types, maximum distance, and distance resolution.
DUT Line Type
Coax Waveguide: Press this soft key to toggle the line type between
coaxial cable and waveguide.
Waveguide List: Press this soft key to open a list box and select a
waveguide type. The Waveguide List menu provides quick navigation aids to
search through the list.
Cutoff Freq: Press this soft key to set the cutoff frequency of the waveguide
that is in use.
Waveguide Loss: Press this soft key to set the waveguide loss coefficient
from 0.000 dB/m to 5.000 dB/m. (The units are dB/ft if units are set to US
units.).
Units
mft:Press this soft key to toggle the units setting between metric units
(meters) and US units (feet).
Back: Press this soft key to return to the “Distance Setup Menu”.
Figure 6-10. Additional Dist Setup Menu (Waveguide)
Back
Distance Info
Waveguide List
Waveguide Loss(dB/m)
#
Cutoff Freq
# Hz
Units
m ft
DUT Line Type
Coax Waveguide
Additional Dist Setup
Page
Down
Page
Up
Top
of
List
Bottom
of
List
Waveguide List
