Distance Domain 9-3 VNA Master Implementation
Vector Network Analyzer MG PN: 10580-00289 Rev. K 9-3
Note
The measured cable had a propagation velocity of 70%, which was entered into
the Vector Network Analyzer. Measurements in the distance domain use the
entered propagation velocity value to calculate the actual physical length of
cables. If the default value of 100% were used, then the measured cable length
would be wrong (4.4 meters in the above example).
Figure 9-2. Distance Domain Measurements of a 3.05 m Cable Showing S
11
and S
21
