1.1.1.11. MX882042C/43C (Non-Call Processing)
Table 1.1.1.11-1 Measurement Software Specifications (MX882042C/43C) (1/2)
Measurement Item
Specifications
Electrical
Typical values (typ.) are only for reference and are not guaranteed.
Frequency/Modulation
Measurement
Frequency 400 to 2700 MHz
3400 to 3800 MHz
(Can be used when installing MT8820C-018 option)
Input level –40 to +35 dBm (Main1)
Carrier frequency
accuracy ±(Set frequency × Reference oscillator accuracy
+15 Hz)
Modulation accuracy
Residual vector error ≤2.5% (400 to 2700 MHz)
(3400 to 3800 MHz, 18° to 28°C)
(When measurement count is 20)
≤3.0% (3400 to 3800 MHz, 20 measurements)
In-band Emissions ≤–40 dB
(≥–10 dBm, Allocated RB≤18)
Measurement object PUSCH
Amplitude
Measurement
Frequency 400 to 2700 MHz
3400 to 3800 MHz
(Can be used when installing MT8820C-018 option)
Input level –60 to +35 dBm (Main1)
Measurement accuracy ±0.5 dB (–20 to +35 dBm)
typ. ±0.3 dB (–20 to +35 dBm)
±0.7 dB (–50 to –20 dBm)
±0.9 dB (–60 to –50 dBm)
400 to 2700 MHz, 10° to 40°C after calibration
±0.5 dB (–20 to +35 dBm, 18° to 28°C),
typ. ±0.3 dB (–20 to +35 dBm, 18 to 28°C),
±0.7 dB (–50 to –20 dBm),
±0.9 dB (–60 to –50 dBmv
3400 to 3800 MHz, 10° to 40°C after calibration
Linearity ±0.2 dB (–40 to 0 dB, ≥–50 dBm),
±0.4 dBv–40 to 0 dB, ≥–60 dBm),
400 to 2700 MHz
±0.2 dB (–40 to 0 dB, ≥–50 dBm, 18° to 28°C),
±0.3 dB (–40 to 0 dB, ≥–50 dBm),
±0.4 dB (–40 to 0 dB, ≥–60 dBm),
3400 to 3800 MHz, 10° to 40°C after calibration
Relative measurement error
<2 dB
typ. ±0.10 dB (–40 to 0 dB, ≥–50 dBm)
Measurement object PUSCH
