Anritsu MT8820C - Page 10

10
1.1.1.10. MX882012C/13C-031
Table 1.1.1.10-1 LTE-Advanced FDD/TDD DL CA 3CCs Measurement Software
Item
Specifications
Function
The reception measurements for DL 3CCs and UL 1CC, and maximum
throughput tests are supported.
The maximum throughput test for DL CA 2x2 MIMO is supported by using with
the MX882012C/13C-011 LTE FDD/TDD 2x2 MIMO DL option.
RF Signal Generator
Output frequency: 400 to 2700 MHz (1-Hz steps)
3400 to 3800 MHz
(Can be used when installing MT8820C-018 option)
Throughput
Measurement
Function: Throughput measurement using RMC
Measurement target: ACK and NACK reported from UE
