9
1.1.1.7. MX882012C/13C-021
Table 1.1.1.7-1 LTE-Advanced FDD/TDD DL CA Measurement Software
Item
Specification
Function
The reception measurements of DL 2CCs and UL 1CC described in Chapter 7 of
3GPP TS 36.521-1 and the maximum throughput tests are supported.
The maximum throughput test for DL CA 2x2 MIMO is supported by using with
the MX882012C/13C -011 2x2 MIMO DL option.
RF Signal Generator
Output frequency: 400 to 2700 MHz (1-Hz steps)
3400 to 3800 MHz
(Can be used when installing MT8820C-018 option)
Throughput
Measurement
Function: Throughput measurement using RMC
Measurement target: ACK and NACK reported from UE
1.1.1.8. MX882012C/13C-022
Table 1.1.1.8-1 LTE-Advanced FDD/TDD UL CA Measurement Software
Item
Specification
Function
When this option is installed with the LTE Advanced FDD/TDD DL CA
measurement software (MX882012C/13C-021) it supports a function to operate
as a Mobile Wireless Device and measurements for RF Transition and
Reception on UL CA.
Intra-Band Contiguous DL CA and UL CA is NOT supported.
Modulation Analysis
Equivalent to MX882012C/13C in respective CC measurements
RF Power
Equivalent to MX882012C/13C in respective CC measurements
Occupied Bandwidth
Equivalent to MX882012C/13C in respective CC measurements
Adjacent Channel
Leakage Power
Equivalent to MX882012C/13C in respective CC measurements
Spectrum Emission
Mask
Equivalent to MX882012C/13C in respective CC measurements
RF Signal Generator
Output frequency: 400 to 2700 MHz (1-Hz steps)
3400 to 3800 MHz
(Can be used when installing MT8820C-018 option)
Throughput
Measurement
Function: Throughput measurement using RMC
Measurement target: ACK and NACK reported from UE
1.1.1.9. MX882012C/13C-026
Table 1.1.1.9-1 LTE-Advanced FDD/TDD DL CA IP Data Transfer
Item
Specifications
Function
IP data transfer with external devices by using Ethernet port of LTE
measurement hardware is supported in DL CA.
