Table 3.8-3: 3GPP Test Items and Test Parameters (3/5)
3GPP Test Item
No.
Test Parameter
6.5.1 Frequency Error
44
RX - Ref. Sens./Freq.Error
6.5.1A.1 Frequency Error for CA (intra-band
contiguous DL CA and UL CA)
44
RX - Ref. Sens./Freq.Error
6.5.2.1 Error Vector Magnitude (EVM) – PUSCH
5
TX1 - Max. Power (QPSK/PartialRB)
6
TX1 - Max. Power (QPSK/FullRB)
7
TX1 - Max. Power (16QAM/PartialRB)
8
TX1 - Max. Power (16QAM/FullRB)
12
TX1 - EVM/IBE/LEAK @ -40 dBm (QPSK/PartialRB)
13
TX1 - EVM @ -40 dBm (QPSK/Full RB)
14
TX1 - EVM @ -40 dBm (16QAM/Partial RB)
15
TX1 - EVM @ -40 dBm (16QAM/Full RB)
6.5.2.1 Error Vector Magnitude (EVM) – PUCCH
20
TX2 - PUCCH EVM @ Max.
23
TX2 - PUCCH EVM/IBE @ -40 dBm
6.5.2.1 Error Vector Magnitude (EVM) – PRACH
2
Idle/Call - PRACH EVM (Test Point1)
3
Idle/Call - PRACH EVM (Test Point2)
6.5.2.1A PUSCH-EVM with exclusion period
41
TX3 - EVM with Exclusion Period (QPSK)
42
TX3 - EVM with Exclusion Period (16QAM)
6.5.2.2 Carrier leakage
10
TX1 - IBE/LEAK @ 0 dBm
11
TX1 - IBE/LEAK @ -30 dBm
12
TX1 - EVM/IBE/LEAK @ -40 dBm (QPSK/PartialRB)
6.5.2.3 in-band emissions
for Non-allocated RB -
PUSCH
General
10
TX1 - IBE/LEAK @ 0 dBm
11
TX1 - IBE/LEAK @ -30 dBm
12
TX1 - EVM/IBE/LEAK @ -40 dBm (QPSK/PartialRB)
IQ Image
10
TX1 - IBE/LEAK @ 0 dBm
11
TX1 - IBE/LEAK @ -30 dBm
12
TX1 - EVM/IBE/LEAK @ -40 dBm (QPSK/PartialRB)
Carrier
Leakage
10
TX1 - IBE/LEAK @ 0 dBm
11
TX1 - IBE/LEAK @ -30 dBm
12
TX1 - EVM/IBE/LEAK @ -40 dBm (QPSK/PartialRB)
6.5.2.3 In-band emissions
for Non-allocated RB -
PUCCH
General
21
TX2 - PUCCH IBE @ 0 dBm
22
TX2 - PUCCH IBE @ -30 dBm
23
TX2 - PUCCH EVM/IBE @ -40 dBm
IQ Image
21
TX2 - PUCCH IBE @ 0 dBm
22
TX2 - PUCCH IBE @ -30 dBm
23
TX2 - PUCCH EVM/IBE @ -40 dBm
Carrier
Leakage
21
TX2 - PUCCH IBE @ 0 dBm
22
TX2 - PUCCH IBE @ -30 dBm
23
TX2 - PUCCH EVM/IBE @ -40 dBm
6.5.2.4 EVM equalizer spectrum flatness
6
TX1 - Max. Power (QPSK/FullRB)
