Table 3.8-4: 3GPP Test Items and Test Parameters (4/5)
3GPP Test Item
No.
Test Parameter
6.5.2A.1.1 Error Vector Magnitude (EVM) for CA
(intra-band contiguous DL CA and UL CA)
5
TX1 - Max. Power (QPSK/PartialRB)
6
TX1 - Max. Power (QPSK/FullRB)
7
TX1 - Max. Power (16QAM/PartialRB)
8
TX1 - Max. Power (16QAM/FullRB)
12
TX1 - EVM/IBE/LEAK @ -40 dBm (QPSK/PartialRB)
13
TX1 - EVM @ -40 dBm (QPSK/Full RB)
14
TX1 - EVM @ -40 dBm (16QAM/Partial RB)
15
TX1 - EVM @ -40 dBm (16QAM/Full RB)
6.5.2A.2.1 Carrier leakage for CA (intra-band
contiguous DL CA and UL CA)
10
TX1 - IBE/LEAK @ 0 dBm
11
TX1 - IBE/LEAK @ -30 dBm
12
TX1 - EVM/IBE/LEAK @ -40 dBm (QPSK/PartialRB)
6.5.2A.3.1 In-band emissions
for Non-allocated RB for CA
(intra-band contiguous DL
CA and UL CA)
General
10
TX1 - IBE/LEAK @ 0 dBm
11
TX1 - IBE/LEAK @ -30 dBm
12
TX1 - EVM/IBE/LEAK @ -40 dBm (QPSK/PartialRB)
IQ Image
10
TX1 - IBE/LEAK @ 0 dBm
11
TX1 - IBE/LEAK @ -30 dBm
12
TX1 - EVM/IBE/LEAK @ -40 dBm (QPSK/PartialRB)
Carrier
Leakage
10
TX1 - IBE/LEAK @ 0 dBm
11
TX1 - IBE/LEAK @ -30 dBm
12
TX1 - EVM/IBE/LEAK @ -40 dBm (QPSK/PartialRB)
6.6.1 Occupied bandwidth
6
TX1 - Max. Power (QPSK/FullRB)
6.6.1A.1 Occupied bandwidth for CA (intra-band
contiguous DL CA and UL CA)
6
TX1 - Max. Power (QPSK/FullRB)
6.6.2.1 Spectrum Emission Mask
5
TX1 - Max. Power (QPSK/PartialRB)
6
TX1 - Max. Power (QPSK/FullRB)
7
TX1 - Max. Power (16QAM/PartialRB)
8
TX1 - Max. Power (16QAM/FullRB)
6.6.2.1A.1 Spectrum Emission Mask for CA (intra-band
contiguous DL CA and UL CA)
5
TX1 - Max. Power (QPSK/PartialRB)
6
TX1 - Max. Power (QPSK/FullRB)
7
TX1 - Max. Power (16QAM/PartialRB)
8
TX1 - Max. Power (16QAM/FullRB)
6.6.2.2 Additional Spectrum Emission Mask
6
TX1 - Max. Power (QPSK/FullRB)
6.6.2.2A.1 Additional Spectrum Emission Mask for CA
(intra-band contiguous DL CA and UL CA)
6
TX1 - Max. Power (QPSK/FullRB)
6.6.2.3 Adjacent Channel Leakage power Ratio
5
TX1 - Max. Power (QPSK/PartialRB)
6
TX1 - Max. Power (QPSK/FullRB)
7
TX1 - Max. Power (16QAM/PartialRB)
8
TX1 - Max. Power (16QAM/FullRB)
