AUTION MAX AX-4030 OPERATING MANUAL
D
8 Tighten the knurled screw to lock the test strip
stopper.
6 Close the cover.
1 Stand the feeder unit straight up.
• Once the feeder is standing up straight, press the
feeder downward until the latch clicks and the unit
locks in place.
2 Close the side cover (a), feeder protective cover (b),
and maintenance cover (c) in that order.
Knurled screw
Test strip stopper
Feeder
unit
Feeder
protective
cover
(a)
(b)
(c)
Side
cover
Maintenance cover
