1-44
AX-4030
AUTION MAX AX-4030 OPERATING MANUAL
Entering Alphanumerics
Use the keys on the operator panel to enter numeric values and alphabetic characters in the entry
fields.
■ Numeric values
Entry fields that accept numeric values (e.g. a measurement number) have the cursor at the right-
most digit.
For example to enter “1302”:
1 Press the numeric keys in the following order, 1, 3,
0, and 2.
REFERENCE: To correct the entry, for example, from “1302” to “1402,” press BS three
times to make it “0001”, then type in “4”, “0”, and “2”. The cursor cannot move through digits.
■ Date
Entry fields that accept date information have the cursor at the “year” entry position at first.
REFERENCE: The default date display format is “YY-MM-DD (year-month-day)”. If you are using
a different format, “month-date-year” or “date-month-year”, set the date accordingly.
For example, to enter April 15th, 2006:
1 To enter the year “06”,
press 0 and 6 in that order, and
press the hyphen key to move to the month entry
position.
2 To enter the month “04 (April)”,
press 0 and 4 in that order, and
press the hyphen key to move to the day entry
position.
3 To enter the day “15”,
press 1 and 5 in that order.
REFERENCE: When specifying a period of days...
To move the cursor from the “start” field to the
“end” field, press .
REFERENCE: To modify the entry, just enter a new value. For example, to change “04” to “06”,
place the cursor at “04” and press 0 and 6 in that order. The cursor cannot move between the
first and second digits (e.g. between “0” and “4”).
