AX-4030
2-5
AUTION MAX AX-4030 OPERATING MANUAL
■ ID
With the barcode reader, the instrument can manage individual samples by IDs read from barcoded
sample tubes. An ID can contain up to 18 digits and can include numbers, alphabet and special
characters (see page 1-45). For port STAT measurement, you can manually input IDs by key
operation. The ID edit feature is helpful to manually modify IDs that are misread by the barcode
reader during measurement.
REFERENCE: Use of the barcode reader
A barcode reader is built into the instrument as a standard feature, and a hand-held barcode
reader is optionally available. The following table lists the ID-managed measurement tasks
supported by each barcode reader.
Barcode readers Normal measurement Port STAT measurement Rack STAT measurement
Built-in type
N/A
Hand-held type N/A N/A
■ Sample rack transportation
The instrument supports two methods for transporting sample racks in the sampler: one way and
loop. The instrument is configured for one-way transportation when shipped from the factory, and
can be changed to loop transportation as needed. For more information, contact your distributor.
One-way transportation (standard)
Up to 5 sample racks (50 samples) can be loaded on the loading side (right side) of the sampler.
The racks are discharged to the unloading side (left side) in turn as sample aspiration finishes.
To Next Page
