AUTION MAX AX-4030 OPERATING MANUAL
Loop transportation
A total of 10 sample racks can be loaded in the sampler at a time: 5 racks on the loading side and
another 5 racks on the unloading side. This means a maximum of 100 samples can be measured
continuously.
The start rack must be placed at the beginning of a batch, and item racks or normal racks, in
remaining locations (numbered 2 to 10 in the figure below). These racks are circulated in the
sampler as the samples are aspirated, and the instrument automatically stops aspiration the next
time it detects the start rack. To employ loop transportation, contact your distributor and ask to
have parameter settings changed.
Start measurement
Start rack
10
9
8
7
6
Start rack
Unloading side
How to load sample racks
Transport direction
2
3
4
5
Stop when start
rack is detected.
Measuring
Rack
detector
Loading side
