Parameter Description
Speed Speed of transceiver in Mbps
Duplex Type of duplexing
Cable Status Values are OK, Open, Short, or Impedance
Distance to Fault The distance in meters to a cable fault (accuracy is +/- 2 meters); displays 0 (zero) if there is
no fault
Pair Skew Difference in propagation between the fastest and slowest wire pairs
Pair Polarity Signals on a wire pair are polarized, with one wire carrying the positive signal and one
carrying the negative signal.
MDI Mode The MDI crossover status of the two wire pairs (1&2, 3&6, 4&5, 7&8), will be either MDI or
MDIX
Using the Event Log for troubleshooting switch problems
The Event Log records operating events in single- or double-line entries and serves as a tool to isolate and
troubleshoot problems.
Once the log has received 2000 entries, it discards the oldest message each time a new message is received.
The Event Log window contains 14 log entry lines. You can scroll through it to view any part of the log.
Once the log has received 2000 entries, it discards the oldest message each time a new message is received.
The Event Log window contains 14 log-entry lines. You can scroll through it to view any part of the log.
NOTE:
The Event Log is erased if power to the switch is interruptedor if you enter the boot system
command. The contents of the Event Log are not erased if you:
• Reboot the switch by choosing the Reboot Switch option from the menu interface.
• Enter the reload command from the CLI.
Event Log entries
As shown in Figure 60: Format of an event log entry on page 330, each Event Log entry is composed of six or
seven fields, depending on whether numbering is turned on or not:
Figure 60: Format of an event log entry
330 Aruba 2530 Management and Configuration Guide for
ArubaOS-Switch 16.05
