11. Calibration
11.1 Calibrating the ACTA 3000
To calibrate the ACTA 3000, we recommend contacting your local Atlas Copco
Tools sales/service representative.
For ACTA 3000 calibration, a traceable calibrated reference transducer box with
cable is needed, part no. 4222 0270 85.
Carry out ACTA 3000 reference transducer box calibration by selecting “Conf”
or “Calibration” and “ACTA” (Conf-2-1).
When calibrating, follow the information windows that are displayed.
Note!
§ If there are less than 30 days to the next calibration date, a message window
appears telling the operator that the ACTA 3000 should be calibrated before
the next calibration date.
§ If the next calibration date has passed, a message window appears telling the
operator that the ACTA 3000 should be calibrated.
