Programming
51
8.3.5 Diagnostics
Re-open menu block “Conf.” (for programming tree, see 7.5 Configuration) and select 3.
Diagnostics.
There are information dialog boxes for displaying the charge left in the battery, calibration
diagnostics for your ACTA, shunt calibration diagnostics for your transducer and track information
on both torque and angle.
Transducer Displays calibration diagnostics for the measuring system (ACTA 3000 and
transducer).
Battery Displays information about battery status and whether the mains is connected or not.
Track This dialog box displays torque and angle continuously. The torque will be updated
only if it rises above the “Cycle start” torque (Prog.-3-2-1). The angle will be set to
zero by pressing the ‘Reset’ key. The ‘Cancel’ key is used to exit from the dialog
box.
8.3.6 Transducer memory
Re-open menu block “Conf.” (for programming tree, see 7.5 Configuration) and select 4.
Transducer memory.
This is an information dialog box displaying the data received from an Atlas Copco memory
transducer. Therefore, if you are using one, you will be able to see the serial number, sensitivity,
calibration torque, torque span, angle encoder, calibration date and the number of measurements
that have been made with that specific transducer.
The transducer memory information is shown in two dialog boxes. To switch between the two
dialog boxes use the right and left arrow softkeys.
Information shown:
§ Type of transducer
§ Serial number
§ Sensitivity
§ Calibration torque
§ Torque span
§ Angle encoder
§ Number of measurements (tightening operations)
