Calibration
129
11.3.6 PowerMac calibration
Use PowerMac calibration to calibrate a PowerMac controller. A new
calibration torque value will be calculated. The new value can be saved in the
controller if communication is set up to the controller. See the figure below.
Display text Comments
P-Set Parameter set used.
X-bar Mean torque value.
X-bar Contr. Mean controller torque. Values are manually entered or
read from controller. Manually entered if communication
not set up to controller.
New cal. torque New calculated calibration torque for controller.
Xbar
ueOldcaltorqueNewcaltorq ⋅=
Old cal. torque Old calibration torque in controller.
Softkey Comments
Read Read values from controller.
Done Mark tightening operations as used in calibration. Printout
question is asked.
Cancel Close window.
Power Macs calibration
