Programming Tree
34
7.2.2 Pop-up Menu
As you can see in the programming tree, some of the menu blocks contain
more than one option / function. Therefore, when selecting a menu block with
more than one function using the blank softkeys, a dialog box as shown below
will appear on the display.
This is a pop-up menu that lists all the options you have under a specific menu
block. To select a function, highlight it by scrolling with the up and down arrows
(again using the blank softkey). Then press ‘Enter’. For even faster selection,
press the digit on the numeric keypad which corresponds to the function you
require.
View, Print etc. Menu Blocks.
Represent programming tree functions or
arrows.
Enter
Measurement Window. This is
your measurement window, which
displays your results. (ACTA Basic
version window is shown here)
Soft Keys. Corresponds to and
controls menu block or arrow
above. Using these you can tab
along the programming tree and
select different functions.
To Next Page
