Atlas Copco ACTA 3000

Measurement Dialog boxes
27
6. Measurement Dialog boxes
6.1 General
The ACTA 3000 features a large back-lit 72 x 96 mm display with a Dialog
box-like interface to allow accurate measurement readings and simple usage.
The ACTA 3000 also features a power-save function that de-activates the
back-lighting on the ACTA 3000 if it is not used for 30 seconds. This is to
save the battery and works only when the ACTA 3000 is powered from the
battery.
6.2 The Different Measurement Dialog boxes
The measurement dialog box can be defined as your active dialog box during
measurements, displaying your results.
There is a maximum of three different measurement dialog boxes (Basic,
Custom and Trace), depending on the version of ACTA 3000.
The bottom row on each measurement dialog box also displays the main parameters
of the programming tree organised in menu blocks. Each measurement dialog box has
its own functionality and therefore its own programming tree (menu block) setup.
Shown below and on the following pages are the measurement dialog boxes for
the different versions of the ACTA 3000, as well as a chart of the measurement
dialog box and menu block setup combinations for each version of the ACTA
3000.
