Technical Specifications
169
15.6.3 Pulse Tool
This setup is obtained when carrying out quick programming with a pulse tool (Q.Prog-2).
Pulse
Tool type Pulse
Target torque 0.75 * Transducer calibration torque * Transducer torque span
Calibration torque 0.75 * Transducer calibration torque * Transducer torque span
Parameter set 0
Controller None
Communication Manual input
Cell ID 0
Channel 1
Model Tensor S
Filter frequency 1500 Hz
Rotation direction CW
Measure strategy Peak
Cycle start 0.05 * Transducer calibration torque
Cycle complete 0.10 * Transducer calibration torque
Start angle 0.12 * Transducer calibration torque
Angle complete Peak torque
Measure delay time 0 ms
Reset time 0 ms
End time 400 ms
Slip torque
9
0.1 Nm
Batch size 0
Subgroup size 5
Subgroup frequency 1
Batch result Off
Torque min. 0.05 * Transducer calibration torque
9
Not used for pulse tool.
