Measurement Dialog boxes
30
6.3 Measurement Dialog box / Menu Block Setup
Combinations
ACTA Version/
Display Measurement
Dialog box
Menu Block Setup (representing the programming tree)
6.3.1 Basic
Basic Dialog box
Stat.. Print Q.Prog..
Speed
Conf.. Cal.. Prog..
6.3.2 Quality Control (QC)
Basic Dialog box
Stat.. Print Q.Prog..
Speed
Conf. Cal. Prog. User
Seq.no. Select Man.In Com.
Custom Dialog box
Stat.. Print Q.Prog..
Speed
Conf. Cal. Prog. User
Seq.no. Select Man.In Com.
