Technical Specifications
185
3. Infrared/RS232
DS
Tool type Direct driven
Target torque Read from controller
Calibration torque 0.75 * Transducer calibration torque * Transducer torque span
Parameter set Read from controller
Controller DS
Communication Infrared or RS232
Cell ID 0
Channel 1
Model Tensor S
Filter frequency 500 Hz
Rotation direction CW
Measure strategy Peak
Cycle start 0.05 * Transducer calibration torque
Cycle complete 0.10 * Transducer calibration torque
Start angle 0.12 * Transducer calibration torque
Angle complete Peak torque
Measure delay time 0 ms
Reset time 0 ms
End time 400 ms
Slip torque
16
0.1 Nm
Batch size 0
Subgroup size 5
Subgroup frequency 1
Batch result Off
Torque min. 0.05 * Transducer calibration torque
Torque max. Transducer calibration torque * Transducer torque span
16
Not used for direct driven tool.
